Rotary Evaporator EV400VAC LabTech

Rotary Evaporator  EV400VAC LabTech is the highest-featured model of the EV400 series, integrating advanced vacuum control along with many other benefits that the EV series has to offer. The built-in vacuum controller allows the user to achieve the correct vacuum in the system from 0-999 mbar for all types of evaporation and ensures high recovery of vapor. The built-in gas release valve ensures high efficiency and stable vacuum control and includes a built-in anticorrosive vacuum sensor with high precision (allows for vacuum control precision of ±1 mbar).

Description

Rotary Evaporator  EV400VAC LabTech is the highest-featured model of the EV400 series, integrating advanced vacuum control along with many other benefits that the EV series has to offer. The built-in vacuum controller allows the user to achieve the correct vacuum in the system from 0-999 mbar for all types of evaporation and ensures high recovery of vapor. The built-in gas release valve ensures high efficiency and stable vacuum control and includes a built-in anticorrosive vacuum sensor with high precision (allows for vacuum control precision of ±1 mbar).

Rotary Evaporator  EV400VAC LabTech
Rotary Evaporator  EV400VAC LabTech is the highest-featured model of the EV400 series, integrating advanced vacuum control.

The EV400VAC’s removable touchscreen display offers an advanced solvent database to optimize evaporation, changing vacuum and rotation settings based on the characteristics of the solvent being used. It is designed to operate on 115V/60Hz with a standard 115V US plug for use with similar electrical requirements. The unit offers vertical motorized lift and has the option for online sample adding through a PTFE valve, granting high efficiency and easy operation. The removable touchscreen display allows for rotation speeds from 20-300rpm. It can handle sample volumes in evaporation flasks ranging from 50-3000mL and has a 5L bath volume.

The system safety EV400VAC is as follows as: 1) The Rotary Evaporator will lift the sample out of the bath to prevent problems 2) It has an automatic protection function that immediately switches off the unit in dry bath conditions. 3) PTFE/FKM sealing offers protection against corrosion. 4) For installation collection flask and evaporation flask use safety clamps.

Every LabTech rotary evaporator comes with a 1L evaporating flask, 1L receiving flask, and vertical condenser as standard. Other glassware assembly configurations (larger flasks, diagonal and dry ice condensers, etc.) are available upon request.



  • Technical Parameter Rotary Evaporator EV400VAC LabTech

  • Part No.                           LEW400V

    Speed Range                  20 – 300 rmp

    Temperature range         Ambient – 180℃

    Temp. Control Mode        PID

    Heating power                1300W

    Bath material                  PTFE coating/SS

    L×W×H                            15×14×28 inches

    Weight                             51  lbs

    Power Supply                 115V, 60Hz
