Digital Cap Torque Tester

The new Digital Cap Torque Tester is a precision instrument that measures OPEN and CLOSE torque values for various applications. As a cap torque analyzer, the CAP-TNP repeatedly determines bottle closure and breakaway torque. It has a wide memory capacity capable of storing 1,000 data points in addition to Average, Maximum and Minimum values. A HI-LO comparator feature can be utilized for a large batch testing to ensure overall product quality.

Description

Digital Cap Torque Tester

The new Digital Cap Torque Tester is a precision instrument that measures OPEN and CLOSE torque values for various applications. As a cap torque analyzer, the CAP-TNP repeatedly determines bottle closure and breakaway torque. It has a wide memory capacity capable of storing 1,000 data points in addition to Average, Maximum and Minimum values. A HI-LO comparator feature can be utilized for a large batch testing to ensure overall product quality.

The Digital Cap Torque Tester is USB capable for computer testing. Combined with the free Digitorq Software, additional analysis and testing can be performed.

The Digital Cap Torque Tester is a portable device powered with internal rechargeable batteries or through an AC Adpater/charger. Designed with a small footprint it can easily be transferred to maximize use around the shop floor or the laboratory.

The CAP-TNP includes free software to analyze your measurement data. The software is Windows 7 compatible and requires Microsoft Excel.

Features Digital Cap Torque Tester

  • Includes Traceable Calibration Certificate
  • ±0.5% F.S. Accuracy
  • Includes Hi/Go/Lo Limits and LED Indicators
  • Displays Torque values in, lb-in, Kgcm and Nm, Ncm
  • USB interface including FREE Digitorq Software
  • Captures Peak Opening, Peak Closing and Average torque values (CCW, CW)
  • Three (3) models offered covering small, medium and large sized containers
  • One touch operation, retains up to 1000 measurements in memory
  • Easy to read L.C.D.
  • Rechargeable NIMH batteries and / or Universal AC adapter
  • Small foot print, compact, space saver design
  • Open Mode:
    Max value when opening
    [CCW torque direction]
  • Close Mode:
    Max value when closing
    [CW torque direction]
  • Average Mode:
    Continuous torque values in real time
  • CE Certified
  • 1 Year Warranty

Torque Ranges Digital Cap Torque Tester

Model Capacity Resolution
CAP-TNP-0.5 0-4.425 Lbf-in
0-0.500 Nm
0-50.00 Ncm
0-5099 gcm
0.001 Lbf-in
0.001 Nm
0.01 Ncm
1 gcm
CAP-TNP-2 0-17.70 Lbf-in
0-2.000 Nm
0-200.0 Ncm
0-20.39 Kgcm
0.01 Lbf-in
0.001 Nm
0.1 Ncm
0.01 Kgcm
CAP-TNP-5 0-44.25 Lbf-in
0-5.000 Nm
0-500.0 Ncm
0-50.99 Kgcm
0.01 Lbf-in
0.001 Nm
0.1 Ncm
0.01 Kgcm
CAP-TNP-10 0-88.5 Lbf-in
0-10.00 Nm
0-1000 Ncm
0-102.0 Kgcm
0.1 Lbf-in
0.01 Nm
1 Ncm
0.1 Kgcm

Typical Torque Values (LB-IN)

Cap dia.
in mm
Phenolic/ Urea
Cap On Glass
Phenolic/Urea
Cap on Plastic
PP/PE Cap
on Glass
PP/PE Cap
on Plastic
Close Torque Open Torque Close Torque Open Torque Close Torque Open Torque Close Torque Open Torque
15 8 4 6 3 12 7 8 4
18 9 5 7 4 13 8 9 5
20 10 5 8 4 15 9 10 5
22 11 6 9 5 17 10 11 6
24 12 6 10 5 18 11 12 6
28 14 7 12 6 21 12 14 7
33 18 9 15 7 24 14 17 8
38 20 10 17 7 29 17 19 9
43 22 11 18 9 33 20 22 11
48 24 14 20 10 26 22 24 12
58 28 14 24 12 44 26 29 14
70 35 18 28 14 52 32 35 17
89 45 22 36 18 65 40 45 22
100 50 25 40 20 75 38 50 25



Dimensions

Digital Cap Torque Tester
The new Digital Cap Torque Tester is a precision instrument that measures OPEN and CLOSE torque values for various applications.
